Topdon TC004 Thermal Imaging Camera with TISR Technology, WiFi, 256×192 IR, 512×384 Enhanced

TOPDON TC004 Thermal Imaging Camera with TISR Technology

High-resolution thermal imaging camera with TISR enhancement, WiFi connectivity, and precision temperature detection.

The TOPDON TC004 is a professional thermal inspection tool built for fast, accurate diagnostics across automotive, electrical, HVAC, and building applications. Featuring a 256×192 infrared sensor with advanced TISR enhancement up to 512×384, it delivers sharper visuals to quickly identify faults, heat loss, and hidden issues.

With ≤40 mK thermal sensitivity, ±2°C accuracy, and a temperature range from -20°C to 550°C, the TC004 ensures reliable results in demanding environments. Built-in WiFi enables seamless image transfer and reporting, while its rugged IP54-rated, drop-tested design and up to 8.5-hour battery life make it ideal for everyday professional use.

Quick Product Overview Video

__

Key Features

• TISR Image Enhancement: Upscales 256×192 thermal images to 512×384 for sharper detail and improved diagnostics.
• High Thermal Sensitivity: ≤40 mK sensitivity detects even subtle temperature differences.
• Wide Temperature Range: Measures from -20°C to 550°C for versatile inspection use.
• 3.5-inch Display: 640×480 resolution screen for clear image viewing and analysis.
• Wireless Connectivity: Built-in WiFi enables fast image transfer and reporting via mobile and PC software.
• Laser Targeting: Built-in laser pointer ensures precise measurement positioning.
• Rugged Design: IP54 rated and 2m drop-tested for workshop and field environments.
• Fast Charging: Fully charges in approximately 2 hours.
• All-Day Battery: Up to 8.5 hours of continuous operation.
• Large Storage Capacity: 64GB eMMC internal storage for images and reports.

__

Functions

• Thermal imaging for automotive diagnostics
• Electrical fault detection and troubleshooting
• HVAC system inspection
• Building heat loss and insulation analysis
• Preventative maintenance inspections
• Image capture, storage, and report generation

__

Technical Specifications

• Infrared Resolution: 256×192
• Enhanced Resolution (TISR): 512×384
• Thermal Sensitivity (NETD): ≤40 mK
• Display: 3.5-inch, 640×480
• Refresh Rate: 25 Hz
• Spectral Range: 8–14 μm
• Pixel Size: 12 μm
• Field of View (FOV): 56° × 42°
• IFOV: 3.75 mrad
• Temperature Range: -20°C to 550°C
• Accuracy: ±2°C or ±2%
• Temperature Resolution: 0.1°C
• Storage: 64GB eMMC
• Battery Capacity: 5000 mAh
• Operating Time: Up to 8.5 hours
• Charging Time: Approx. 2 hours
• Connectivity: WiFi
• Software Support: TopInfrared (Mobile), TopView (PC)
• Protection Rating: IP54
• Drop Test: 2 meters

__

Compatibility

• Compatible with Android and iOS via TopInfrared app
• Compatible with PC via TopView software

__

What’s in the Box

• 1x TOPDON TC004 Thermal Imaging Camera
• 1x Universal Travel Adapter
• 1x USB Cable (USB-A to USB-C)
• 1x User Manual
• 1x Storage Bag
• 1x Product Certificate
• 1x Calibration Certificate
